Description
023U7562 Filter drier core DCR 100
Contact us for more information
023U7562 Filter drier core DCR 100
Product number:
RDG7620
| Product Group : | Danfoss |
|---|
General Information
| Product Group : | Danfoss |
|---|---|
| Activated Alumina / Molec. Sieve. : | 0/100 % |
| Model Number : | 023U7562 |
| Specification Key : | 100-DM |
| Type : | 100-DM |
Additional Info
| Additional Info : | High capacity |
|---|
Capacity
| Acid Capacity : | 7.99 g |
|---|
Driers
| Core Size : | 100 cu.in. |
|---|---|
| Solid Core Surface : | 1055 cm² |
| Solid Core Volume : | 1587 cm³ |
Drying Capacity
| Drying Capacity 24°C (Drops of Water) : | R134a: 3712, R404A: 3867, R407C: 3605, R410A: 3361, R452A: 3835, R507: 4050, R1234ze: 3967 |
|---|---|
| Drying Capacity 52°C (Drops of Water) : | R134a: 3398, R404A: 3663, R407C: 3323, R410A: 2989, R452A: 3572, R507: 3643, R1234ze: 3567 |
Logistical Information
| Commodity Code : | 68159900 |
|---|---|
| Country Of Origin : | MEX |
| EAN : | 5702428182416 |
| Gross Weight : | 1.348 kg |
Measurements
| Weight : | 1.35 kg |
|---|
Refrigerant
| Refrigerant : | R22/R407C, R134a, R401A, R402A, R404A, R409A, R410A, R421A, R422D, R502, R507A, R744 |
|---|
| File name | Extension | Size |
|---|---|---|
| Technical Literature | 2.96 MB |
