ASV25-BS Sinclair Caravan Unit 9000BTU R32
Contact us for more information
ASV25-BS Sinclair Caravan Unit 9000BTU R32
Product number:
ASV25BS
| Product Group : | Caravan Units |
|---|
General Information
| Product Group : | Caravan Units |
|---|---|
| Model Number : | ASV25BS |
Additional Info
| Family : | 1 |
|---|
Air Volume/Air Flow
| Air Flow (Low/Medium/High) : | 200/250/330 m³/h |
|---|
Cooling Capacity
| Cooling Capacity : | 2.6 kW |
|---|
Electrical
| Power Supply : | 220-240/1/50 V/Ph/Hz |
|---|
Energy Efficiency/Performance
| COP : | 2.2 |
|---|---|
| EER : | 2.3 |
Heating Capacity
| Heating Capacity : | 2.4 kW |
|---|
Indoor Unit Attributes
| Depth (IU) : | 610 mm |
|---|---|
| Height (IU) : | 49 mm |
| Net Weight (IU) : | 2.7 kg |
| Width (IU) : | 485 mm |
Outdoor Unit Attributes
| Depth (OU) : | 1077 mm |
|---|---|
| Height (OU) : | 283 mm |
| Width (OU) : | 720 mm |
Refrigerant
| Refrigerant : | R32 |
|---|---|
| Refrigerant Charge : | 0.47 kg |
Sound Power/Pressure
| Sound Pressure Level : | 53 dB(A) |
|---|
Temperature
| Temperature Range Cooling : | 18 ~ 46 °C |
|---|---|
| Temperature Range Heating : | - 5 ~ 24 °C |
| File name | Extension | Size |
|---|---|---|
| User Manual | 10.18 MB | |
| Conformity Declaration | 275.27 KB | |
| Brochures | 3.22 MB |
Set Component Parts
ASV-25BSI Sinclair Caravan Unit 9000BTU Indoor- R32
ASV-25BSI Sinclair Caravan Unit 9000BTU Indoor - R32
ASV-25BSO Sinclair Caravan Unit 9000BTU Outdoor- R32
ASV-25BSO Sinclair Caravan Unit 9000BTU Outdoor- R32
