Description
CAJ2446ZBR Low Temp Commercial Condensing Unit on R507A / R404
Product number:
RLK2320
| Product Group : | Tecumseh Low Temperature Units 220V |
|---|
General Information
| Product Group : | Tecumseh Low Temperature Units 220V |
|---|---|
| Receiver Volume : | 2.35 L |
Air Volume/Air Flow
| Air Flow : | 900 m³/h |
|---|
Compressor
| Compressor Model : | CAJ2446Z |
|---|---|
| Power Supply Compressor : | 230/1/50 V/Ph/Hz |
Connections
| Liquid Line Connection : | 3/8 in, 9.52 mm |
|---|---|
| Suction Line Connection : | 1/2 in, 12.7 mm |
Electrical
| Max Current : | 8.4 A |
|---|
Fan
| Fan Blade Size : | 300 mm |
|---|---|
| Fan Diameter : | 300 mm |
| Fan Power : | 30 W |
| Number Of Fans : | 1 |
| Power Supply Fan : | 230/1/50 V/Ph/Hz |
Measurements
| Height : | 340 mm |
|---|---|
| Length : | 481 mm |
| Weight : | 34.0 kg |
| Width : | 432 mm |
Motor
| Motor Type : | CSR |
|---|
R404A Performances
| R404A Cooling Capacity Rated -35°C : | 0.54 kW |
|---|
R452A Performances
| R452A Capacity -10°C : | 1.66 kW |
|---|---|
| R452A Capacity -15C : | 1.38 kW |
| R452A Capacity -20°C : | 1.13 kW |
| R452A Capacity -25°C : | 0.90 kW |
| R452A Capacity -30°C : | 0.70 kW |
| R452A Capacity -35°C : | 0.52 kW |
| R452A Capacity -40°C : | 0.37 kW |
| R452A Power Input -35°C : | 0.61 kW |
Refrigerant
| Refrigerant : | R404A, R448A, R449A, R452A, R507 |
|---|
Sound Power/Pressure
| Sound Pressure Level LP 10m : | 62 dB(A) |
|---|
