Description
Compressor Scroll SH090A4ALC POE Oil Stub Tube R410A
Contact us for more information
Compressor Scroll SH090A4ALC POE Oil Stub Tube R410A
Product number:
RDM5500
| Product Group : | Danfoss Scroll for Air Conditioning R410A |
|---|
General Information
| Product Group : | Danfoss Scroll for Air Conditioning R410A |
|---|---|
| Colour : | Blue |
| Model Number : | SH090A4ALC |
| Type : | SH |
Capacity
| Capacity Control : | Fixed speed |
|---|
Compressor
| Power Supply Compressor : | 400/3/50 460/3/60 V/Ph/Hz |
|---|---|
| Swept Volume : | 88.40 cm³ |
| Technique : | Scroll |
Connections
| Connection Type : | Brazed |
|---|---|
| Discharge Connection Height : | 451 mm |
| Discharge Connection Pipe Size : | 7/8 in |
| Discharge Line Connection Size : | 7/8 in |
| Suction Connection Height : | 235 mm |
| Suction Connection Pipe Size : | 1 1/8 in |
| Suction Line Connection Size : | 1 1/8 in |
Cooling Capacity
| Cooling Capacity : | 92.49 kBtu/h |
|---|---|
| Cooling Capacity at 50Hz : | 19.8 kW |
| Cooling Capacity at 60Hz : | 27.1 kW |
Electrical
| Frequency : | 50/60 Hz |
|---|---|
| IP Class : | IP54 |
| LRA : | 98 A |
| MCC : | 22 A |
| Max Operating Current : | 19 A |
| Phase : | 3 |
| RLA : | 14.3 A |
| Voltage : | 400/460 V |
Heating Capacity
| Heating Capacity 50Hz : | 19.8 kW |
|---|
Logistical Information
| Commodity Code : | 84143081 |
|---|---|
| Country Of Origin : | CHN |
| EAN : | 5702428980883 |
| Gross Weight : | 61.91 kg |
Measurements
| Diameter : | 243 mm |
|---|---|
| Height : | 482 mm |
| Net Weight : | 58 kg |
| Weight : | 58.00 kg |
Oil
| Oil Charge : | 3.0 L |
|---|---|
| Oil Type : | POE |
Pressure
| Higher Active Pressure : | 48.7 Bar |
|---|---|
| Lower Active Pressure : | 33.3 Bar |
Refrigerant
| Max Refrigerant Charge : | 5.90 kg |
|---|---|
| Refrigerant : | R410A |
| Refrigerant Charge : | 5.9 kg |
