Description
Compressor Scroll SY240A4CBI Stub Tube
Contact us for more information
Compressor Scroll SY240A4CBI Stub Tube
Product number:
RDM6240
| Product Group : | Danfoss Scroll for Air Conditioning |
|---|
General Information
| Product Group : | Danfoss Scroll for Air Conditioning |
|---|---|
| Colour : | Blue |
| Model Number : | SY240A4CBI |
| Type : | SY240A4CBI |
Capacity
| Capacity Control : | Fixed speed |
|---|
Compressor
| Power Supply Compressor : | 400/3/50 460/3/60 V/Ph/Hz |
|---|---|
| Swept Volume : | 347.80 cm³ |
| Technique : | Scroll |
Connections
| Connection Type : | Brazed |
|---|---|
| Discharge Connection Height : | 654 mm |
| Discharge Line Connection Size : | 1 1/8 in |
| Suction Connection Height : | 196 mm |
Electrical
| Frequency : | 50/60 Hz |
|---|---|
| IP Class : | IP54 |
| LRA : | 215 A |
| MCC : | 50 A |
| Power Supply : | 400/3/50 V/Ph/Hz |
| RLA : | 35.7 A |
Logistical Information
| Commodity Code : | 84143081 |
|---|---|
| Country Of Origin : | FRA |
| EAN : | 5702428660747 |
| Gross Weight : | 168 kg |
Measurements
| Diameter : | 344 mm |
|---|---|
| Height : | 727 mm |
| Weight : | 151.00 kg |
Oil
| Oil Charge : | 8 L |
|---|
Pipes
| Pipe Diameter : | 1 1/8 in |
|---|
Refrigerant
| Max Refrigerant Charge : | 16 kg |
|---|---|
| Refrigerant : | R22, R134a, R407C, R513A |
| File name | Extension | Size |
|---|---|---|
| Safety Data Sheet | 595.71 KB | |
| Conformity Declaration | 449.83 KB | |
| Conformity Declaration | 384.92 KB | |
| Conformity Declaration | 261.28 KB | |
| Conformity Declaration | 218.64 KB | |
| Conformity Declaration | 406.36 KB | |
| Conformity Declaration | 393.53 KB | |
| Conformity Declaration | 915.78 KB | |
| Conformity Declaration | 1.37 MB | |
| Conformity Declaration | 4.47 MB | |
| Conformity Declaration | 671.76 KB | |
| Conformity Declaration | 1.16 MB | |
| Installation Manual | 1.74 MB | |
| Conformity Declaration | 1.17 MB |
