Differential Pressure Switch, MP54
Contact us for more information
Differential Pressure Switch MP54
Product number:
RDD4069
| Product Group : | Danfoss KP1 & KP15 Pressure Switches |
|---|
General Information
| Product Group : | Danfoss KP1 & KP15 Pressure Switches |
|---|---|
| Equipment : | Thermal time relay |
| Model Number : | 060B016891 |
| Type : | MP54 |
Connections
| Connection Size : | 1/4 in |
|---|---|
| Connection Type : | Flare |
| Pressure Connection Type : | Flare |
Electrical
| Contact Function : | SPDT |
|---|---|
| Electric Connection : | Female Screwed cable entry |
| Electric Connection Size : | Pg13.5 |
| IP Class : | IP20 |
Logistical Information
| Commodity Code : | 90322000 |
|---|---|
| Country Of Origin : | IND |
| EAN : | 5702424499808 |
| Gross Weight : | 0.784 kg |
Measurements
| Weight : | 0.68 kg |
|---|
Pressure
| Diff : | 0.2 Bar |
|---|---|
| Max Operating Pressure : | 17.0 Bar |
Standards
| Approval : | CCC, CE, CMIM, DNV∙GL, EAC, LLC CDC EURO-TYSK, LVD, RoHS China, TYSK, UKCA |
|---|
Temperature
| Ambient Temperature Note : | Bellows max 100 °C/212 °F |
|---|---|
| Ambient Temperature Range : | -40-60 °C |
