Description
SUH13BITB Sinclair Terrel Inverter 13000 BTU R32 Black H/Wall Split
Contact us for more information
SUH13BITB Sinclair Terrel Inverter 13000 BTU R32 Black H/Wall Split
Product number:
SUH13BITB
| Product Group : | Sinclair |
|---|
General Information
| Product Group : | Sinclair |
|---|---|
| Model Number : | SUH13BITB |
Cooling Capacity
| Cooling Capacity : | 3.5 kW |
|---|
Electrical
| Power Supply : | 220-240/1/50 V/Ph/Hz |
|---|
Heating Capacity
| Heating Capacity : | 3.8 kW |
|---|
Indoor Unit Attributes
| Depth (IU) : | 212 mm |
|---|---|
| Height (IU) : | 294 mm |
| Net Weight (IU) : | 11 kg |
| Width (IU) : | 889 mm |
Pipes
| Max Piping Length : | 15 m |
|---|---|
| Min Piping Length : | 3 m |
Refrigerant
| Refrigerant : | R32 |
|---|---|
| Refrigerant Charge : | 0.57 kg |
Sound Power/Pressure
| Sound Pressure Level : | 42 dB(A) |
|---|
Temperature
| Outdoor Operating Temp. Range (Cooling) : | -15 ~ 50 °C |
|---|---|
| Outdoor Operating Temp. Range (Heating) : | - 25 ~ 30 °C |
| File name | Extension | Size |
|---|---|---|
| Energy Label | png | 61.57 KB |
| Owners Manual | 7.3 MB | |
| Installation Manual | 2.95 MB | |
| Brochures | 1.6 MB |
Set Component Parts
SIH13BITB Sinclair Terrel Inverter 13000 BTU R32 Black Indoor
SIH13BITB Sinclair Terrel Inverter 13000 BTU R32 Black Indoor
SOH13BIT Sinclair Terrel Inverter 13000 BTU R32 Outdoor
SOH13BIT Sinclair Terrel Inverter 13000 BTU R32 Outdoor
