TAG4568T Medium Temp Commercial Compressor on R22
Contact us for more information
TAG4568T Medium Temp Commercial Compressor on R22
Product number:
RLH2230
| Product Group : | Tecumseh Med Temp 400V |
|---|
General Information
| Product Group : | Tecumseh Med Temp 400V |
|---|---|
| Model Number : | 2831830102 |
| Type : | Reciprocating Compressors |
Application
| Application : | HBP - High Back Pressure |
|---|
Compressor
| Displacement : | 124.4 cc |
|---|
Connections
| Discharge Line Connection Size : | 5/8 in |
|---|---|
| Suction Line Connection Size : | 1 1/8 in |
Electrical
| LRA : | 59 A |
|---|---|
| MCC : | 0 A |
| MOC : | 15.6 A |
| Phase : | 3 |
| Power Supply : | 400/3/50 V/Ph/Hz |
| Voltage : | 400 V |
Measurements
| Height : | 423 mm |
|---|---|
| Length : | 361 mm |
| Weight : | 50 kg |
| Width : | 238 mm |
Motor
| Motor Type : | 3PH |
|---|
Oil
| Oil Charge : | 1960 cc |
|---|---|
| Oil Type : | Mineral |
Pressure
| Diff : | -6.7 °C, 12.8 °C |
|---|
Refrigerant
| Refrigerant : | R22 |
|---|
